FT-301系列智能粉末电阻率测试系统 （升级版）
FT-301 Series intelligent powder resistivity test system (upgrade)
概述：采用一体化结构设计，将粉末比电阻的测量与粉体电阻率/电导率分析为一体式，测量与数据分析全部通过PC软件完成，粉体压强与电阻值、电阻率、电导率值的变化关系；粉体受到压缩直至平稳时，描述了粉体在压缩体积变化过程中，电性能的变化趋势，采用全自动操作模式运行，自动数据分析与管理。四端法测量模式。
Overview: the integration structure design, the powder ratio resistance measurements and powder resistivity/conductivity analysis for one-piece, measurement and data analysis was done by the PC software, The change relationship between the powder pressure and resistance, the resistivity and the conductivity; Powder is compressed until smooth, describes the changing trend of the electrical properties in the process of compression volume. Using automatic operation mode, automatic data analysis and management. Four terminal method of measurement.
适用范围：需要对电性能进行分析的导电性粉末，如：碳素粉末厂、焦化厂、石化厂、粉末冶金厂等生产加工企业部门；高等院校、科研部门，质量检验机构，质量管理部门，研发部门等。
Scope of application: to analyze the electrical conductive powder, such as: carbon powder plant, coking plant, petrochemical plant, powder metallurgy factory etc production and processing enterprises sector; university, scientific research department, quality inspection organization, quality management department, r&d department, etc.
|
规格型号/ model |
FT-301A |
FT-301B |
FT-301C |
FT-301D |
|
|
1.电阻/ resistance |
1×10-8—2×105Ω |
10-7～2×107Ω |
10-6～2×106Ω |
10-5～2×106Ω |
|
|
2.电阻率范围/ Resistivity |
1×10-8—2×105Ω-cm |
10-7～2×107Ω-cm |
10-6～2×106Ω-cm |
10-5～2×106Ω-cm |
|
|
3.电导率/ Conductivity |
5 ×10-5～1×108ms/cm |
5×10-7～107ms/cm |
5×10-6～106ms/cm |
5×10-6～105ms/cm |
|
|
4.测试电流范围/ current |
0-10A，最小100uA |
1μA，10μA，100μA，1mA，10mA，1000mA |
|||
|
5.测量电压量程/ Voltage |
0-2v；分辨率： 0.1μv 精度0.1%
|
电压量程/ voltage：2mV 分辨率/ 20mV 200mV 2V Resolution：0.1uV 测量精度±（0.1%）/、 Accuracy ± (0.1%) |
|||
|
6.电流精度/ Current Accuracy |
±0.1% |
±0.1% |
±0.2%
|
||
|
7.电阻精度/ Resistance Accuracy |
≤0.3%标准电阻/ standard resistance 分辨率0.01μΩ |
≤0.3%标准电阻/ standard resistance 分辨率0. 1μΩ |
|||
|
8.PC软件界面/display |
电阻值、电阻率、电导率值、温度、压强值、单位自动换算、横截面、高度等 resistance, resistivity, conductivity, temperature, pressure value, the unit automatically conversion, cross-section, height |
||||
|
9.测试方式/Test mode |
四端测量法/Four-terminal measurement method |
||||
|
10.传感器压力/Pressure Sensors |
200kg；(其他规格可以定制) / (Other specifications can be customized) |
||||
|
11.粉末模具/Powder Mold |
模具：内径10mm；高：25mm ；内径20mm；高：25mm（选购） Mold: inner diameter 10mm, height: 25mm, inner diameter 20mm, height: 25mm (choose to buy) |
||||
|
12.工作电源/power supply |
输入: AC 220V±10% ,50Hz 功 耗：<60W Input: AC220V ± 10%, 50Hz Power consumption: <60W |
||||
|
13. 主机外形尺寸/dimensions |
约H700mm*L650mm*D300mm about H700mm*L650mm*D300mm |
||||
|
14.净重量/Net Weight |
约45kg about 45kg |
||||
|
15. 标配外选购/Others buy |
1.标准校准电阻1-5个；2.电脑和打印机依据客户要求配置；4.计量证书1份 1. Standard calibration resistor 1-5. 2. computers and printers based on customer configuration requirements. 3. Measurement certificate 1.
|
||||
